Mini Compact Excavator B&S VANGUARD 408cc 14hp Engine, 65.7” Max. Digging...

ENGINE Model Vanguard 25V000 Displacement 408cc No.Of Cylinders 1 Engine Output 14hp Stroke 2.638in Warranty for Engine 3-Year Bore 3.465in Fuel Tank 1.52 gal Rated speed 3600rpm Engine Oil 0.7gal TRAVEL SYSTEM Max. Travel Speed 0.75 mile/h Ground Pressure 5.1psi Maximum Traction Force 3035 lbf Gradeability - Maximum Maximum 30 degrees Ground Clearance 15.9in Operating Weight 2370lbs HYDRAULIC SYSTEM Hydraulic Oil Tank 3.96gal Max.Discharge Flow 4.65 gpm SWING SYSTEM Swing Speed 8rpm Tail Swing Radius 32.6in DIGGING FORCE Bucket Digging Force 1619 lbf Arm Digging Force 1191 lbf Bucket Capacity 0.7 ft³ Bucket Width 15 in SCOPE OF WORK Max.Digging Height 109 in Min Turning Radius Of Working Device 48.1in Max.Dumping Height 80 in Max. Lifting Height Dozer Blade 5.9in Max.Digging Depth 65.7in Max. Depth Dozer Blade 7.4in Max.Vertical Digging Depth 62.6in Boom Swing - Left 53° Max Digging Radius 119in Boom Swing - Right 40° Max.digging Radius At Ground Level 118.7in DIMENSIONS Transportation Length 82in/115in Crawler Wheel Base 36in Overall Width 37in Track Belt/Shoe Width 7in Overall Height（To Top Of Cab） 88.5in Track Length 48.5in Counter Weight Ground Clearance 16in Track Width 37in SERVICE Package Method Wood Case Warranty for Machine 1 Year Packing Size 91x40x98 in Weight (N.W./G.W.) 2180/2440 lbs WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
